GCR PRO Power Cable DIY EU plug Schuko - knife terminals socket Cu
Article:
GCR-55486
Color:
Wire AWG:
Length, in meters:
| Article | GCR-55486 |
| Model | GCR-P302 |
| Cable type | Schuko |
| Length, in meters | 1.5 |
| Color | black |
| Jacket material | PVC |
| Conductor material | CU |
| Wire AWG | 3*1,0mm |
| Connector A | Schuko plug |
| Connector B | fork terminals |
| Brand | GCR |
PROF series power cable with Schuko plug and terminal connectors at the end is designed for creating a high-quality 220V connection for various electrical equipment.
Features:
DIY – Do It Yourself
Angled Schuko Euro plug
Reliable connection – 6.3mm blade terminals
Copper conductor
Cable cross-section: 3*1.0mm², PROF series
Durable protective PVC sheath
The power cable is made of high-quality materials and consists of a three-core wire with a copper conductor cross-section of 1.0mm². It features a molded angled Euro plug with a grounding contact on one end and stripped wires prepared for further use on the other end, crimped with 6.3mm blade terminals (male connector). The sturdy outer PVC sheath provides excellent protection for the conductors against external damage and bending, preserving the cable’s integrity and ensuring a long service life. The blade terminals feature lock-type fasteners that snap into place when paired with matching connectors, ensuring a convenient and reliable contact connection. It is an excellent choice for replacing damaged or worn-out wires in household appliances and other devices connected to a 220V network.
Specifications:
Cable connector type: Angled Euro plug CEE 7/7 (Schuko) / 3 x blade male terminals (6.3mm)
Sheath type: PVC
Conductor material: Copper
Conductor cross-section: 3*1.0mm²
Rated voltage: 220V
Total rated load power: 3500W
Load current: 16A
Features:
DIY – Do It Yourself
Angled Schuko Euro plug
Reliable connection – 6.3mm blade terminals
Copper conductor
Cable cross-section: 3*1.0mm², PROF series
Durable protective PVC sheath
The power cable is made of high-quality materials and consists of a three-core wire with a copper conductor cross-section of 1.0mm². It features a molded angled Euro plug with a grounding contact on one end and stripped wires prepared for further use on the other end, crimped with 6.3mm blade terminals (male connector). The sturdy outer PVC sheath provides excellent protection for the conductors against external damage and bending, preserving the cable’s integrity and ensuring a long service life. The blade terminals feature lock-type fasteners that snap into place when paired with matching connectors, ensuring a convenient and reliable contact connection. It is an excellent choice for replacing damaged or worn-out wires in household appliances and other devices connected to a 220V network.
Specifications:
Cable connector type: Angled Euro plug CEE 7/7 (Schuko) / 3 x blade male terminals (6.3mm)
Sheath type: PVC
Conductor material: Copper
Conductor cross-section: 3*1.0mm²
Rated voltage: 220V
Total rated load power: 3500W
Load current: 16A
